PC/GF20 Black
Polycarbonate
PC/GF20 Black
(Glass fiber 20% reinforced)
- Heat Resistance
- 146℃
- Tensile Strength
- 93MPa
- Chemical Resistance
- Excellent acid resistance
- Price
- ★★
Characteristics
- Excellent balanced mechanical properties.
- Excellent rigidity in a wide range temperature.
- Flameretardancy.
Applications
- Camera housing, lens hood cover, battery box, OA equipment, smartphone housing.
Attention
- Use in hot water or steam can cause hydrolysis
- Be careful as using solvents and cutting oils may cause dissolution and environmental stress cracking
Properties
| ITEM | UNIT | ASTM Method | PC・PC Black | PC/GF20 |
|---|---|---|---|---|
| Specific gravity | - | D792 | 1.2 | 1.35 |
| Water absorption immersion 24h | ％ | D570 | 0.24 | 0.11 |
| Tensile strength | MPa | D638 | 62 | 93 |
| Tensile elongation | ％ | D638 | 115 | 4 |
| Flexural strength | MPa | D790 | 85 | 157 |
| Flexural modulus | MPa | D790 | 2,300 | 5,400 |
| Izod impact strength | J/m | D256 | 870 | 111 |
| Rockwell hardness | - | D785 | M65 | M98 |
| Heat deflection temperature 1.82MPa | ℃ | D648 | 136 | 146 |
| Flammability | - | （UL94） | 丸棒HB/0.38*、板V-2/0.44 | HB/0.4、V-2/0.75、V-0/1.5 |
| Coefficient of linear thermal expansion | xE-5/℃ | D696 | 6.5 | 2.4 |
| Crystal melting temperature | ℃ | - | ー | ー |
| Glass transition temperature | ℃ | - | 150 | 150 |
| Volume resistivity | Ω・cm | D257 | 2 x E16 | ー |
| Dielectric constant 1MHz | - | D150 | 2.5 | 2.7 |
| Dielectric loss tangent 1MHz | - | D150 | 0.0082 | 0.0074 |
| Dielectric strength | MV/m | D149 | 20 | 23 |
Product Size Table
Notes
The application examples described are for reference only,the use is not guaranteed.
Please refer to the SDS for handling (transport, storage, molding, disposal).
Espechially please confirm the suitability and safety for food use, medical use, safety equipment, toys, etc.
Our products may correspond export trade control items,please check the relevant laws and regulations.
